Microscope Trinocular YR0241: Practical Use in Laboratories
The Microscope Trinocular YR0241 is an exceptional tool designed for various laboratory applications. This microscope integrates advanced features to provide enhanced observation capabilities. With a robust design and user-friendly functionalities, it is ideal for both educational and professional settings.
Product Description
The YR0241 model comes with a Siedentopf trinocular head that is inclined at 30 degrees, allowing for comfortable viewing for extended periods. Its interpupillary distance ranges from 55 to 75 mm, accommodating users of different eye distances. The coarse and fine focus knobs offer a movement range of 24 mm with a fine division of 0.004 mm for precise focusing.
This microscope is equipped with a quadruple backward revolving nosepiece, which allows for easy switching between four different achromatic objectives: 4x, 10x, 40x, and 100x. It also features a wide-field eyepiece of WF10x/18 for expanded visual range.
For illumination, the YR0241 utilizes a 3W LED light source with adjustable brightness. The Abbe condenser with NA 1.25 comes with an iris diaphragm and filter, enhancing the quality of light for various specimens.
Market Price
| Feature | Description |
|---|---|
| Model | YR0241 |
| Price (USD) | $168.00 |
| Brand | Kalstein |
| Weight | 6.5 kg |
| Dimensions | 16.5 x 21.5 x 38 cm |
Frequently Asked Questions
What are the main features of the YR0241 microscope?
The YR0241 microscope features a trinocular head, multiple objective lenses, a wide-field eyepiece, and adjustable LED illumination, making it versatile for numerous laboratory applications.
Is the focus mechanism precise?
Yes, the coarse and fine focus knobs provide a movement range of 24 mm with fine division of 0.004 mm, allowing for precise adjustments during observations.
How does the illumination work?
The microscope uses a 3W LED light source with adjustable brightness, ensuring optimal lighting conditions for different specimen types.
What is the interpupillary distance range?
The interpupillary distance of the YR0241 can be adjusted between 55 mm and 75 mm to accommodate various users comfortably.
What is the weight of the microscope?
The YR0241 microscope has a weight of 6.5 kg, which provides stability during use while remaining portable for laboratory settings.
Can additional accessories be added to the microscope?
Yes, optional accessories such as eyepieces, phase contrast kits, and polarizing attachments can be added to enhance the microscope's capabilities.
Pros and Cons
Pros
- High-quality optics for clear images
- Adjustable interpupillary distance for user comfort
- Coarse and fine focus for precise adjustments
- LED illumination with adjustable brightness
- Quadruple revolving nosepiece for versatility in objectives
Cons
- May require additional investments for optional accessories
- Weight may be a consideration for some users
Field Usage
The YR0241 microscope is well-suited for various laboratory applications, including biological research, materials science, and educational environments. Its trinocular feature allows for the attachment of cameras for documentation and sharing of findings. The microscope's design and capabilities make it a valuable asset in clinical, educational, and research institutions, where high-quality imaging is essential.
Recommendations
For those looking to enhance their laboratory capabilities, the Microscope Trinocular YR0241 is highly recommended. It offers a perfect blend of functionality and ease of use. Whether you are a student learning the basics of microscopy or a professional conducting in-depth research, this model meets the demanding requirements of modern laboratories.
Request a quote today to explore how the YR0241 microscope can meet your laboratory needs.
