Biological + USB Portable Dual Lens Digital Microscope YR05783 // YR05786
Biological + USB Portable Dual Lens Digital Microscope YR05783 // YR05786 — equipo de laboratorio Kalstein con especificaciones técnicas, características avanzadas y soluciones profesionales certificadas para uso científico.
The Biological + USB Portable Dual Lens Digital Microscope YR05783 // YR05786 is a versatile and innovative tool ideal for both educational and professional settings. With its dual lens system, this microscope offers incredible versatility in magnification, allowing for detailed observation and analysis. Equipped with a 7" IPS LCD screen, users can easily view high-resolution images directly on the device. The portable design and USB connectivity make this microscope convenient for use in various locations, whether in the lab, classroom, or field. With support for Micro SD storage up to 32GB, capturing and saving images or videos has never been easier.
Price in the Market
The market price for the Biological + USB Portable Dual Lens Digital Microscope varies depending on the retailer and included accessories. Generally, prices for similar digital microscopes with dual lenses and LCD displays range from $800 to $1650. Interested buyers can get a more accurate quote through the Kalstein Plus platform, ensuring they receive the best deal available.
Frequently Asked Questions
What is the maximum magnification of this microscope? The microscope offers a magnification range from 4x to 100x, thanks to its achromatic objectives and WF10x/16x eyepieces.
Is the microscope compatible with both Windows and Mac? Yes, the included measuring software supports both Windows and iMac systems.
Advantages and Disadvantages
Advantages: The microscope provides excellent image clarity and detail, thanks to its high-quality lenses and digital enhancements. The dual lens system and portability are significant benefits for on-the-go users. Its LED lighting system ensures optimal visibility in various lighting conditions.
Disadvantages: While the device is highly capable, users who require higher magnification levels might find its range somewhat limiting. Additionally, the maximum supported storage of 32GB may require frequent offloads for heavy users.
Product Use in the Field
In practical applications, this microscope is highly valued for its portability and ease of use. Whether in educational demonstrations or detailed inspections in the field, the Biological + USB Portable Dual Lens Digital Microscope provides a robust solution for clear, real-time visualization and detailed analysis. Its USB output makes it simple to transfer and share findings with colleagues or students.
Recommendations
To maximize the lifespan and efficiency of the microscope, it's recommended to handle it with care during transport and use. Regular cleaning of the lenses with proper cleaning solutions will help maintain image clarity. Additionally, utilizing the one-key photo and video features can aid in documenting observations efficiently.
Features
Key features of the Biological + USB Portable Dual Lens Digital Microscope include a 7" IPS LCD screen, USB connectivity, compatibility with Windows and Mac systems, and a flexible magnification range with dual lens capability. Its portable design makes it excellent for fieldwork or lab use.
Technical Specifications
| Model | YR05784 | YR05785 | YR05786 | YR05783 | |
| Head | Teaching Head, 45°+90° Inclined, 360° Rotatable | o | o | ||
| Binocular Head, 30° Inclined, 360° Rotatable | |||||
| Trinocular Head, 30° Inclined, 360° Rotatable | o | o | |||
| LCD Camera | 7"IPS LCD Screen Resolution 800x480 | ||||
| Sensor | 1/2.75"CMOS | ||||
| Resolution | 2.0M 1920x1080p, With 0.3x C-Mount | ||||
| Pixel Size | 2.8x2.8um | ||||
| Frame Rate | 30 fps | ||||
| Output | USB 2.0, Output to LCD, PC or Mobile Phone | ||||
| Power | DC5V/2A, Power Port 3.5/1.35 DC | ||||
| Storage | Micro SD Card Slot, Support Class 10 Max 32G | ||||
| LCD Menu | One Key Switch Image From Main Camera & Hand-held Camera | ||||
| One Key Take Photo, Video, Record, Save to SD Card | |||||
| Set Color, Contrast, White Balance Auto/Manual Adjust | |||||
| Set Photo/ Video Resolution Adjust, Mic On/Off to Record Voice With Video | |||||
| Set Date, Time | |||||
| Choose Language: Chinese, Tranditional Chinese, English, Japanese, France, Germany, Korea, Russia, Italy, Portuguese, Spanish, Arabic | |||||
| Playback Photo, Video | |||||
| PC Software | CD With Measuring Software Strange View, Support Win/iMac Computer, Support Language Chinese, English, Russia, Ukrian | ||||
| Hand-held | USB Portable Digital Microscope 1.3M, 1.5x-25x | - | o | - | o |
| Eyepiece | WF10x, WF16x | ||||
| Nosepiece | Quadruple Nosepiece, Ball Bearing Inner Locating | ||||
| Objective | Achromatic 4x,10x,40x(s), 100x(s, oil) | ||||
| Working Stage | Double Layer Mechanical Stage 115*125mm | ||||
| Focusing | Coaxial Coarse & Fine Focus Knob, Coarse Focusing Range 20mm | ||||
| Condenser | Abbe Condenser N.A.1.25, With Iris Diaphragm Filter | ||||
| Light Source | LED, Brightness Adjustable | ||||
| Accessory | Prepared Slide 10pcs in Box, | ||||
| Experiment Kit, | |||||
| Mobile Phone Connector | |||||
| Power Adapter | |||||
| Power Cord | |||||
| USB Cable | |||||
| Software CD | |||||
| Packing | Hand Carry Box + Master Carton | ||||
Technical specifications
| Weight | 5 kg |
|---|---|
| Manufacturer | Kalstein |
Available models
- Biological + USB Portable Dual Lens Digital Microscope YR05783 // YR05786 - YR05783 (SKU: YR05783)
- Biological + USB Portable Dual Lens Digital Microscope YR05783 // YR05786 - YR05784 (SKU: YR05783)
- Biological + USB Portable Dual Lens Digital Microscope YR05783 // YR05786 - YR05785 (SKU: YR05783)
- Biological + USB Portable Dual Lens Digital Microscope YR05783 // YR05786 - YR05786 (SKU: YR05783)
