Elisa Microplate Reader YR06096
Elisa Microplate Reader YR06096 — equipo de laboratorio Kalstein con especificaciones técnicas, características avanzadas y soluciones profesionales certificadas para uso científico.
The Elisa Microplate Reader YR06096 stands out in the market with its advanced 8-channel optical fiber system, designed to enable rapid reading for a 96-well plate. Whether you're performing end point, kinetic, or two-point calculations, this reader offers precise results with an absorbance range from 0 to 4.000Abs. It also boasts a highly adjustable plate shaking system, adaptable speed and time settings, and multiform test reports. Compatible with all popular printers and providing a powerful internet connection for remote data sharing, this model is essential for modern laboratories.
Market Price
The average market price for microplate readers of this caliber typically ranges from $1800 to $2600 USD. While prices can vary based on features and brand reputation, the Elisa Microplate Reader YR06096 offers exceptional value for its advanced technological capabilities and reliable performance.
Frequently Asked Questions
Q: Is this microplate reader compatible with all types of microplates?
A: Yes, it is compatible with standard 96-well plates and other kinds of microplates and strips.
Q: Can the reader save data if there is a power outage?
A: Absolutely, the device is designed to automatically save data in unexpected power-off situations.
Q: Is there software support for multiple languages?
A: Yes, multiple language software is available upon request.
Advantages and Disadvantages
Advantages: The Elisa Microplate Reader YR06096 provides high accuracy and resolution, quick reading time, remote connectivity, and data safety features. It also accommodates a broad language range and printer compatibility.
Disadvantages: Although packed with features, the initial setup may require some technical expertise, and additional filters are optional, incurring extra cost.
Field Use
In practical scenarios, the Elisa Microplate Reader YR06096 is ideal for laboratories conducting quantitative and qualitative analysis. Its rapid reading capability minimizes experiment time, thereby increasing efficiency and throughput. The adjustable shaking and precise wavelength filters make it versatile for various biochemical assays.
Recommendations
Regularly calibrate the device to maintain accuracy and ensure optimal performance. Utilizing the remote data sharing feature can significantly enhance the collaborative efforts of your research team. Keep the light source and optical system clean to avoid any readings' discrepancies.
Features
- 8-channel optical fiber system for rapid 96-well plate reading.
- Multiple calculation modes including end point and kinetic.
- Adjustable plate shaking speed and time.
- Comprehensive data safety features.
- Seamless remote connectivity for data sharing.
- Multi-language software availability.
- Extensive memory for up to 100,000 test results.
Technical Specifications
| Model | YR06096 |
| Absorbance Range | 0 - 4.000Abs |
| Resolution | 0.001Abs(displayed),0.0001Abs(calculated) |
| Accuracy | ±0.003Abs |
| Type of Microplate | Standard with 96-well or other kind of microplate and strip |
| Optic System | 8-channel optic fiber system |
| Light Source | Halogen lamp, 6.5V/19W |
| Wavelengths | 405, 450, 492, 630nm, 4 more filters optional |
| Wavelength Accuracy | ±2nm |
| Band Width | ‹8nm |
| Methodologies | End Point, fixed time, Kinetic |
Calculation Method | ABS, Cut-Off, Single Standard Curve, Multi-Percent, Percent log, Linear, Exponential |
| Power. 4PL Regression | |
| Reading Speed | 6 seconds for 96 well plate(single wavelength) |
| Shaking Plate | Shaking time and speed adjustable |
| Operation | PC operation, bidirectional communications |
| Memory | More than 100 programs, up to 100,000 test results |
| Printer | All printers compatible with Windows |
| Interface | RS-232 |
| Language | English or any language on request |
| Power Supply | AC 100V-240V,50Hz/60Hz |
| Net Weight | 6.2KG |
| Dimensions L. × W × H(mm) | 454 × 295 × 146 |
Technical specifications
| Weight | 7.5 kg |
|---|---|
| Manufacturer | Kalstein |
