Phase contrast microscope YR05792-1

ManufacturerKalstein

Description

The Phase Contrast Microscope YR05792-1 stands out as an exceptional instrument for biological microscopy, enriched with advanced phase contrast capabilities. It features a classic 107BN design, integrated with a 40x phase contrast objective, and a specialized condenser, allowing for enhanced visualization of transparent specimens. With its high-brightness 3W LED light source and adjustable brightness settings, this microscope ensures clear and vivid imaging. The large mechanical stage is both robust and versatile, offering precision movement across a 140×140 mm platform.

Market Price

The cost of high-quality phase contrast microscopes like the YR05792-1 generally spans a broad range, typically between $700 and $1200 in the market. This variability depends on the specific features and additional functionalities offered by the different models. It is always advisable to consider these variations when searching for the best deal.

Frequently Asked Questions

What is phase contrast microscopy used for? Phase contrast microscopy is primarily used for viewing live, unstained specimens, making it invaluable in cell biology research.

Does the microscope come with a warranty? Yes, the Phase Contrast Microscope YR05792-1 usually comes with a manufacturer’s warranty. Please check the details when purchasing from authorized retailers.

Advantages and Disadvantages

The main advantage of the YR05792-1 microscope is its capability to provide detailed imaging of transparent and colorless specimens without staining. Its LED illumination system also offers energy efficiency and longevity. However, the complexity of phase contrast systems might pose a challenge for beginners unfamiliar with the setup process.

Field Use

In practical scenarios, this microscope is used extensively in labs for observing cellular structures and microorganisms. Its precise focusing system and ergonomic design make it suitable for prolonged use, delivering exceptional clarity and resolution in research settings.

Recommendations

To ensure optimal performance of the Phase Contrast Microscope YR05792-1, it is recommended to regularly clean the lenses and maintain the mechanical components. Investing in a good quality camera adapter is also advisable for documentation purposes.

Features

  • Classic 107BN biological microscope of phase contrast version
  • Phase contrast objective 40x, phase contrast condenser for 40x
  • 10x centering telescope, green filter included. PH 40x, 100x Optional
  • Large mechanical stage 140×140 mm, movable range 50×75 mm
  • High brightness 3W LED light source, adjustable brightness

Technical Specifications

Model YR05792-1
Phase contrast 40x phase-contrast objective, Abbe NA1.25 condenser, 40x phase-contrast diaphragm, 10x telescope, green filter
Type of power supply AC 110V-240V
Transmitting Light Halogen 6V20W or LED
Type of light source halogen
Capacitor NA Mirror
Capacitor type 1.25
Capacitor characteristics Abbe + Iris diaphragm
Focusing scale Filter holder
Focus range Iris diaphragm
Type of approach Rack and pinionↆ↑.
Focusing functions 0.002 mm
Working in motion stage 37.7 mm
Size of the working stage Coaxial Coarse and Fine
Type of work stage Adjustable tension
Target Safety stop locking ring
Type of target 50x75mm, Accuracy 0.1mm
Nozzle holes 140x140mm
Nozzle characteristics 2 mechanical layers
Ocular Achromatic 4x/0,10, 10x/0,25, 100xs/1,25 (oil)
Eyepiece diameter Achromatic
Diopter of the head 4 holes
Interpupillary head Exterior
Head rotation WF10x/18 mm, 2 pcs. WF16x/11 mm, 2 pcs.
Head tilt 23.2 mm
Head type Both tubes adjustable
Standard extension 55~75mm
Optical system 360° head rotation
Standard function 45°

Additional information

Weight 6,5 kg
