Description
The YR01829 Benchtop Conductivity Meter is a state-of-the-art instrument designed for precise conductivity measurements. Featuring a 7-inch colored capacitive touch screen, it offers high resolution and sensitivity, ensuring user-friendly operation. With its built-in microprocessor, it provides intelligent functions such as automatic calibration and temperature compensation (ATC). This versatile device supports wireless Bluetooth printing, real-time data transfer via Bluetooth, and extensive data storage capabilities of up to 2000 sets. Ideal for laboratories and research facilities, the meter’s advanced measurement technology covers conductivity, TDS, salinity, and resistivity, ensuring exceptional accuracy and reliability.
Price in the Market
The price for high-quality benchtop conductivity meters like the YR01829 generally ranges from $500 to $800. This pricing reflects the advanced features and reliability these devices offer to professionals in various fields.
Frequently Asked Questions
What is the measurement range for this device? The YR01829 can measure conductivity from 0.5 µS/cm to 200 mS/cm, supporting a wide range of applications.
Can it store data? Yes, the meter can store up to 2000 sets of data, which can be transferred to a USB stick and accessed via Excel.
Advantages and Disadvantages
Advantages: The YR01829 offers accurate measurements, user-friendly operation with its capacitive touch screen, and extensive data storage. It’s also equipped with Bluetooth and USB connectivity for seamless data handling. Disadvantages: As a high-tech instrument, it may require a learning curve for users unfamiliar with advanced measurement devices.
Product Use in the Field
The YR01829 is widely used in laboratories, water treatment plants, and research facilities to accurately measure conductivity, TDS, and more. Its advanced features ensure reliable results for both basic and complex applications.
Recommendations
For optimal performance, it is recommended to regularly calibrate the device and to store it in a clean, dry location. Utilize the ATC conductivity electrode to ensure precise and fast measurements.
Key Features
- High-resolution 7-inch capacitive touch screen
- Automatic calibration and temperature compensation
- Bluetooth connectivity and USB data output
- Extensive data storage with Excel compatibility
- Comprehensive measurement range and accuracy
- Smart electrode status display
Technical Specifications
| Model | YR01829 | |
|
pH
|
Measuring range | (-1.999 ~ 19.999)pH |
| Resolution | 0.1/0.01/0.001 pH | |
| Accuracy | Electrode: ±0.002 pH, Meter: ±0.01 pH | |
| Auto calibration | 1, 2, 3 point | |
| Buffer | Europe & USA, NIST, China standards | |
| Input current | ≤1×10 -12 A | |
| Input impedance | ≥3×10 12Ω | |
| Stability | ±0.002 pH/3h | |
| Temp. compensation | (0 ~ 100)°C, auto or manual | |
|
mV
|
Measuring range | -1999.9mV ~ 0 ~ 1999.9mV |
| Resolution | 0.1 mV | |
| Accuracy | ±0.03% FS | |
|
Cond.
|
Measuring range
|
Conductivity |
| (0.00~20.00)μS/cm, (20.0~200.0)μS/cm | ||
| (200~2000)μS/cm, (2.00~20.00)mS/cm | ||
| (20.0~200.0)mS/cm | ||
| (200~2000)mS/cm (K=10) | ||
| TDS: (0 ~ 100)g/L | ||
| Salinity: (0 ~ 100)ppt | ||
| Resistivity: (0 ~ 100)MΩ·cm | ||
| Resolution | 0.01/0.1/1μS/cm; 0.01/0.1/1mS/cm | |
| Accuracy | Electrode: ±0.5% FS, Meter: ±0.8% FS | |
| Temp. compensation range | (0 ~ 100)°C, auto Electrode constant 0.1/0.5/1/5/10/50/100 cm -1 | |
| Reference Temp. | 25°C, 20°C, 18°C | |
|
Temp.
|
Range | (-10 ~ 110)°C |
| Resolution | 0.1°C | |
| Accuracy | 5 ~ 60°C:±0.4°C Others: ±0.8°C | |
|
Other
|
Display | 7-inch colored capacitive touch screen |
| Data storage | 1000 sets | |
| Power | 12V/1A | |
| Output | USB | |
| Ambient Temp. | 15 ~ 30 °C | |
| Ambient Humidity | ≤85% | |
| IP grade | IP54 | |
| Dimensions/N.W. | 215×170×37mm/600g | |
| Shipping Size/G.W. | 470x430x72mm/3kg | |
