Technical Performance and Safety of the YR0240-1 Trinocular Microscope
The YR0240-1 Trinocular Microscope is designed for both professional and educational use, combining advanced optical technology with user-friendly features. This microscope is ideal for those in need of precise imaging and robust functionality in laboratory settings.
Product Description
The YR0240-1 Trinocular Microscope incorporates a range of features that enhance its usability and versatility. It includes a dark field condenser (dry and oil) for optimal specimen visibility, ensuring that users can achieve high-quality images under various conditions. The Seidentopf binocular viewing head, inclined at 30 degrees, allows for comfortable prolonged use, accommodating inter-pupillary distances between 47 mm and 78 mm.
Fine and coarse coaxial adjustments enable precise focusing, with a fine division of 0.002 mm and a mobile range of 25 mm. This level of detail is crucial for applications requiring meticulous observation.
Technical Specifications
| Specification | Details |
|---|---|
| Model | YR0240-1 |
| Optical System | Finite optical system |
| Eyepiece | WF10X/18 |
| Viewing Head | Trinocular Seidentopf, 30° inclined, interpupillary 47-78 mm |
| Objectives | 4X, 10X, 20X, 40X, 100X (achromatic) |
| Condenser | NA1.25 Abbe; dark field condenser (dry, oil) |
| Stage | Mechanical stage, 140x140 mm, mobile range 75x50 mm |
| Illumination | Halogen lamp 6V/20W; S-LED lighting |
| Weight | 10 kg |
Market Price
The current market price for the YR0240-1 Trinocular Microscope is approximately $316.00. This competitive pricing reflects its advanced features and high-quality performance, making it a valuable investment for both educational institutions and professional laboratories.
Comparison with Previous Model
| Feature | YR0240-1 | YR0240 |
|---|---|---|
| Optical System | Finite optical system | Finite optical system |
| Eyepiece | WF10X/18 | WF10X/18 |
| Viewing Head | Trinocular, 30° inclined | Binocular, 30° inclined |
| Objectives | 5 Achromatic (4X-100X) | 4 Achromatic (4X-100X) |
| Condenser | NA1.25 Abbe; dark field | NA1.25 Abbe |
| Stage | Mechanical, 140x140 mm | Mechanical, 140x140 mm |
| Illumination | Halogen & S-LED | Halogen |
Frequently Asked Questions
What is the maximum magnification of the YR0240-1 microscope?
The YR0240-1 microscope offers a maximum magnification of 100X, thanks to its high-quality achromatic objectives.
Can the YR0240-1 be used for both dry and oil immersion techniques?
Yes, the YR0240-1 supports both dry and oil immersion techniques, making it versatile for various types of specimens.
What is the weight of the YR0240-1 microscope?
The YR0240-1 microscope weighs approximately 10 kg, providing stability during use.
Is the YR0240-1 suitable for educational purposes?
Absolutely! The YR0240-1 is designed for both professional and educational use, making it ideal for schools and universities.
Does it come with a warranty?
Yes, the YR0240-1 typically comes with a manufacturer’s warranty, ensuring peace of mind for users.
What type of illumination does the YR0240-1 use?
The YR0240-1 uses a Halogen lamp and S-LED lighting for optimal specimen viewing.
Where can I request a quote for the YR0240-1?
You can easily request a quote for the YR0240-1 microscope through our online platform, ensuring quick and efficient service.
Pros and Cons
Pros
- High-quality optical performance with multiple objectives
- Comfortable viewing with adjustable interpupillary distance
- Supports both oil immersion and dry techniques
- Dual illumination systems enhance visibility
- Sturdy and durable construction suitable for heavy usage
Cons
- Can be heavy for portability
- Initial setup may require calibration
Field Usage
The YR0240-1 Trinocular Microscope is widely used in various fields including biology, medical research, and educational institutions. Its advanced features allow for clear and detailed observations of specimens, making it a favorite among scientists and educators alike. The ability to switch between different illumination techniques allows professionals to adapt to various specimen types and observation needs.
Recommendations
For best results, it is recommended to use the YR0240-1 with high-quality slides and properly prepared specimens. Regular maintenance and cleaning of the optics will ensure longevity and consistent performance. Additionally, consider utilizing the microscope in conjunction with digital imaging equipment for enhanced documentation and analysis.
