Description
The Benchtop Conductivity/DO Meter YR06384 is an advanced laboratory instrument designed for precise measurement of conductivity and dissolved oxygen levels. It features a 7-inch colored capacitive touch screen with a high resolution of 1024×600, allowing for intuitive navigation and clear display of results. Its intelligent microprocessor offers functions like automatic calibration, temperature compensation, data storage of up to 1000 sets, and connectivity options such as USB, RS232, and Bluetooth. This device is ideal for labs requiring meticulous data transfer and storage capabilities, supported by its built-in clock display and optional real-time Bluetooth data transfer to mobile devices.
Market Price
The average market price for benchtop conductivity and DO meters ranges from $1200 to $2000, reflecting the technological advancements and features provided by models like the YR06384. With its comprehensive functionality, the YR06384 offers a balance between quality and cost-effectiveness, making it a competitive choice among laboratory professionals.
Frequently Asked Questions
How does the automatic calibration work? The YR06384 utilizes an intuitive automatic calibration feature for both conductivity and dissolved oxygen measurements, allowing for quick and precise adjustments based on the type of standard solution used.
What data connectivity options are available? This meter supports multiple data connectivity options including USB, RS232, and Bluetooth, allowing for versatile data management and transfer solutions.
Advantages and Disadvantages
Advantages: The YR06384 offers multifunctional measurement capabilities, high accuracy, advanced data management, and seamless connectivity which are ideal for professional laboratory settings. Its intuitive touch screen interface simplifies operation.
Disadvantages: Due to the advanced features, it might present a slight learning curve for users unfamiliar with high-tech laboratory equipment, and its initial cost may be significant for smaller labs.
Product Usage in the Field
This meter is employed extensively in laboratories looking to accurately measure electrical conductivity and dissolved oxygen levels in various samples. Its auto-recognition of 8 conductivity standard solutions and real-time data transfer capabilities are invaluable in research and quality control environments.
Recommendations
To ensure optimal performance of the YR06384, users should regularly perform maintenance checks, ensure the electrodes are stored properly, and frequently update data records using the device’s robust storage system. For easy data analysis, exporting data to Excel via USB is recommended.
Features
- 7-inch colored capacitive touch screen
- Auto calibration and temperature compensation
- Data storage for 1000 sets with USB and Bluetooth options
- Switchable between conductivity, TDS, salinity, and resistivity modes
- Polarographic DO electrode with auto salinity and pressure compensation
Technical Specifications
| Model | YR06384 | |
|
Cond.
|
Measuring range
|
Conductivity: |
| (0.00~20.00)μS/cm, (20.0~200.0)μS/cm | ||
| (200~2000)μS/cm, (2.00~20.00)mS/cm | ||
| (20.0~200.0)mS/cm, | ||
| (200~2000)mS/cm (K=10) | ||
| TDS:(0 ~ 100)g/L | ||
| Salinity:(0 ~ 100)ppt | ||
| Resistivity:(0 ~ 100)MΩ·cm | ||
| Resolution | 0.01/0.1/1μS/cm; 0.01/0.1mS/cm | |
| Accuracy | Electrode: ±0.5% FS, Meter: ±0.8% FS | |
| Temp. compensation range | (0 ~ 50)ºC, auto | |
| Electrode constant | 0.1/0.5/1/5/10/50/100 cm-1 | |
| Reference Temp. | 25ºC,20ºC,18ºC | |
|
DO
|
Measuring range | (0 ~ 20.00)mg/L(ppm) (0 ~ 200.0)% |
| Resolution | 0.1/0.01 mg/L(ppm) 1/0.1 % | |
| Accuracy | Electrode: ±0.10 mg/L, Meter: ±0.40 mg/L | |
| Response time | ≤30s (25ºC, 90%response) | |
| Residual current | ≤0.1 mg/L | |
| Temp compensation | (0 ~ 45)ºC, auto | |
| Salinity compensation | (0 ~ 45) ppt, auto | |
| Pressure compensation | (80 ~ 105) kPa, auto | |
| Auto calibration | Air saturated by water; water saturated by air | |
| Electrode type | Polarographic | |
|
Temp.
|
Range | (-10 ~ 110)ºC |
| Resolution | 0.1ºC | |
| Accuracy | 5 ~ 60ºC:±0.4ºC Others: ±0.8ºC | |
|
Other
|
Display | 7-inch colored capacitive touch screen |
| Data storage | 1000 sets | |
| Power | 12V/1A | |
| Output | USB, RS232, Bluetooth | |
| Ambient Temp. | 15 ~ 30 ºC | |
| Ambient Humidity | ≤85% | |
| IP grade | IP54 | |
| Dimensions/N.W. | 240×170×70mm/600g | |
| Shipping Size/G.W. | 470x430x85mm/2.6kg | |
