Description
The Portable Conductivity/DO Meter YR06382 is an essential tool for professionals requiring precise and efficient water quality measurements. Featuring a large LCD screen with adjustable white backlight, it’s equipped with a microprocessor chip, providing intelligent functions like auto calibration, automatic temperature compensation (ATC), and data storage. This compact device adapts to conductivity, Total Dissolved Solids (TDS), salinity, and resistivity measurements, ensuring high precision across a wide range. With its advanced DO mode, the meter includes features like automated salinity compensation and a polarographic DO electrode for fast polarization.
Price in the Market
The pricing for portable conductivity and dissolved oxygen meters varies widely based on features and specifications. Typically, such devices range from $700 to $1200. However, to obtain a precise quote for the Portable Conductivity/DO Meter YR06382, we encourage you to visit our Kalstein Plus platform for an immediate quotation.
Frequently Asked Questions
What is the battery life of the Portable Conductivity/DO Meter YR06382? The device operates with two AA batteries, providing extended use under normal conditions.
Is this device waterproof? Yes, it carries an IP57 rating, making it both dustproof and waterproof.
Advantages and Disadvantages
One significant advantage of the YR06382 is its multifunctionality, allowing users to measure different water quality parameters with a single device. The large data storage capacity of 200 sets enhances field efficiency. On the downside, users may need to manually calibrate pressure compensation for certain measurements, which requires additional handling.
Product Use in the Field
This meter is typically used in water treatment facilities, environmental monitoring, and aquaculture due to its high accuracy and reliability in measuring crucial water quality metrics. The meter’s portability and durable design make it ideal for on-site assessments.
Recommendations
For optimal performance, ensure regular calibration and maintenance of the electrodes. Store the device in a clean, dry place when not in use to preserve its longevity. Utilize the auto-power-off feature to conserve battery life during field operations.
Features
- Large LCD screen with adjustable backlight
- Auto calibration and temperature compensation
- Data storage capacity of 200 sets
- Waterproof and dustproof design
- Multiple measurement modes: conductivity, TDS, salinity, and resistivity
Technical Specifications
| Model | YR06382 | |
|
Cond.
|
Measuring range
|
Conductivity: |
| (0.00~19.99)μS/cm | ||
| (20.0~199.9)μS/cm | ||
| (200~1999)S/cm | ||
| (2.00~19.99)mS/cm | ||
| (20.0~199.9)mS/cm | ||
| TDS:(0~100)g/L | ||
| Salinity:(0~100)ppt | ||
| Resistivity:(0~100)MΩ·cm | ||
| Resolution | 0.01/0.1/1μS/cm; 0.01/0.1 mS/cm | |
| Accuracy | ±1.0% FS, Overall:±1.5% FS | |
| Temp. compensation | (0~100)ºC(Auto/manual) | |
| Electrode constant | 0.1 / 1 / 10 cm-1 | |
|
DO
|
Measuring range | (0 ~ 20.00) mg/L(ppm), (0 ~ 200.0)% |
| Resolution | 0.1/0.01 mg/L(ppm), 1/0.1 % | |
| Accuracy | Electrode: ±0.10 mg/L, Instrument: ±0.40 mg/L | |
| Response time | ≤30s (25ºC, 90%response) | |
| Residual current | ≤0.1 mg/L | |
| Temp. compensation | (0 ~ 45)ºC (auto) | |
| Salinity compensation | (0 ~ 45) ppt (auto) | |
| Pressure compensation | (66 ~ 200) kPa (manual) | |
| Auto calibration | Air saturated by water, water saturated by air | |
| Electrode type | Polarographic | |
|
Temp.
|
Measuring range | (0 ~ 100)ºC |
| Resolution | 0.1ºC | |
| Accuracy | 5 ~ 60ºC:±0.4ºC Others: ±0.8ºC | |
|
Other
|
Data storage | 200 sets |
| Power | Two AA batteries (1.5V x2) | |
| Ambient Temp. | 5 ~ 35 ºC | |
| Ambient humidity | ≤85% | |
| IP grade | IP57 Dustproof and waterproof | |
| Dimensions/N.W. | (65×120×31)mm/180g | |
| Shipping size/G.W. | (460×300×55)mm/1Kg | |
