Doppler Fetal Monitor YR02180

Manufacturer: Kalstein

Description

Introducing the Doppler Fetal Monitor YR02180, a versatile and reliable medical device designed for use in Operating Theatres (OT) and Intensive Care Units (ICU). This semi-modular parameter patient monitor features a 17-inch LCD screen, offering six standard parameters: ECG, SpO2, TEMP, NIBP, RESP, and PR/HR. With its robust configuration, including a 5-lead ECG, RESP, Dual-Temp, and more, the YR02180 ensures high precision and reliability in critical medical environments.

Market Price Overview

The Doppler Fetal Monitor YR02180 is competitively priced in the market, with a general price range between approximately $3,500 and $4,200 USD. This competitive pricing reflects its advanced features and high utility in clinical settings. While prices may vary slightly based on region and supplier, the YR02180 remains a valuable investment for healthcare providers seeking a quality monitoring solution.

Frequently Asked Questions

What are the main features of the Doppler Fetal Monitor YR02180?
The YR02180 offers parameters such as ECG, SpO2, TEMP, NIBP, RESP, and PR/HR, with optional configurations like touch screen and thermal recorder.

Can the YR02180 be customized?
Yes, it includes optional upgrades like Masimo/Nellcor SpO2, Dual-IBP, and more, allowing customization based on specific needs.

Advantages and Disadvantages

The Doppler Fetal Monitor YR02180 boasts numerous advantages such as a large display, multiple parameters, and customization options, making it a versatile choice for medical professionals. However, potential downsides might include its higher price compared to more basic models and the need for training to utilize its full capabilities effectively.

Field Usage

In practical settings, the YR02180 is utilized for precise monitoring of fetal heart rate and other vital signs, providing critical data to healthcare professionals during surgeries and in intensive care scenarios. Its configurability and reliable accuracy make it a trusted tool in dynamic healthcare environments.

Recommendations

To maximize the effectiveness of the YR02180, regular calibration and maintenance are recommended. Additionally, users should ensure they are familiar with its comprehensive features through adequate training. For inquiries or to generate an automatic quote, visit the Kalstein Plus platform.

Features

  • 17-inch LCD display
  • Semi-modular with six standard parameters
  • Customizable options including touch screen and thermal recorder
  • Reliable accuracy and sensitivity
  • Usable in both OT and ICU settings

Technical Specifications

Model YR02180
ECG
Lead mode 5 Leads(RA,LA,LL,RL,V)
Connection method I, II, III,AVR,AVL,AVF,V
Lead Mode 3 Leads (RA,LA,LL)
Connection method I, II,III
Gain x250, x500, x1000, x2000
Accuracy ±5%
Resolution 1bpm
Sensitivity >200(uVp-p)
Differential input impedance ≥5MΩ
ST segment Monitoring Range
Measure Range -1.0~+1.0mV
Measure Accuracy -0.8mV~+0.8mV
Heart Rate
Measuring range 40~240bpm
Accuracy ±3bpm
Resolution 1bpm
Sensitivity >200UVp-p
Respiration
Method Impedance between R-F(RA-LL)
Measuring Impedance Range 0.3~3.0 MΩ
Bandwidth 0.1~2.5Hz
Respiration Rate Adult: 7~120BrPM
Neo/Ped 7~150BrPM
Resolution 1 BrPM
Accuracy ±2 BrPM
NIBP
Method Oscillometric
Measuring Interval in AUTO Mode 1,2,3,4,5,10,15,30,60,90,120,180,240(Min)
Measuring Period in STAT Mode 5 Min
Pulse Rate Range 40~240bpm / 40~150bpm
Alarm Type SYS, DIA, MEAN
Resolution
Pressure 1mmHg
SPO2
Display Number of SPO2,waveform of capacity,Pulse
Measuring range 0~100%
Resolution 1%
Accuracy 70~99% (±2%)
Pulse rate range 0~300bpm
TEMP
Channel 2
Measuring and Alarm Range 0~50ºC
Resolution 0.1ºC
Accuracy 0.1ºC
Actualization interval about 1 Second.
Average Time Constant <10 Second.

Additional information

Weight 8 kg
