Non-contact Benchtop Spectrophotometer YR05483
Non-contact Benchtop Spectrophotometer YR05483 — Kalstein laboratory equipment with technical specifications, advanced features, and certified professional solutions for scientific use.
The Non-contact Benchtop Spectrophotometer YR05483 is a state-of-the-art color measuring instrument designed for precise non-contact color measurement of liquids, sauces, powders, and more. Developed independently by Kalstein, the YR05483 features a 45/0 optical geometry to provide accurate color analysis and transmission. This spectrophotometer excels in laboratories, R&D industries, and automated production lines. Its innovative design offers stability and high-precision measurement, preventing sample damage and cross-contamination during the process.
Market Price
The Non-contact Benchtop Spectrophotometer YR05483 generally falls within a market price range of $10,000 to $10,800 USD. This competitive pricing reflects the advanced technology and features incorporated into this sophisticated instrument.
Frequently Asked Questions
- What industries can the YR05483 be used in? The YR05483 is versatile and applicable in cosmetics, food hygiene, plastics, electronics, paint and ink, printing, ceramics, and more.
- How does the non-contact feature work? The spectrophotometer measures color without touching the sample, using a 45/0 optical geometry, ensuring no damage or contamination.
- What is the lifespan of the illuminant? The full spectrum LED light source has a lifespan of over five years, supporting more than three million measurements.
Advantages and Disadvantages
Advantages: The YR05483 offers high precision in non-contact measurements, a robust set of measurement modes, real-time data display on a large touch screen, and significant data storage capacity. Disadvantages: Its sophisticated features might be more than necessary for basic applications, and the price may be a consideration for smaller operations.
Usage in the Field
In practical scenarios, the YR05483 spectrophotometer is employed for quality control on production lines, allowing operators to monitor and maintain color consistency efficiently. In laboratories, it aids in rigorous research and development tasks, offering reliable data to support complex analysis.
Recommendations
For optimal performance, regular calibration using the standard calibration board should be conducted. Ensure the spectrophotometer remains in the specified working environment to extend its lifespan. Take advantage of the PC software for enhanced functionalities.
Features
- Non-contact, 45/0 geometric optical structure
- Large 7" TFT capacitive touch screen
- Multiple measurement modes: Sample, QC, Continuous Statistics
- Built-in camera for precise locating
- Full spectrum LED light source
- Data storage for up to 30,000 samples (Sample mode + QC mode)
Technical Specifications
| Model | YR05483 |
| Illumination System | 45/0 method(45 ring-shaped illumination, vertical viewing);Conforms to CIE No.15,GB/T 3978,GB 2893,GB/T 18833,ISO7724-1,ASTM E1164,DIN5033 Teil7,GB 2893,GB/T 18833 |
| Features | 45/0 non-contact benchtop spectrophotometer can achieve precise non-contact measurement between the measuring probe and the sample like liquids, sauces, powders, etc. It can be applied for accurate color analysis and transmission in laboratories and R & D industries; it can also be used for accurate color measurement and quality control of automated production lines; it is widely used in cosmetics, fruits and vegetables, food hygiene, plastic electronics, paint and ink, printing, ceramics and other industries. |
| Light Source | Full spectrum LED light |
| Spectrophotometric Mode | Concave Grating |
| Sensor | 256 Image Element Double Array CMOS Image Sensor |
| Wavelength Range | 400~700nm/10nm output |
| Reflectance Range | 0~200% |
| Measuring Aperture | Φ20mm |
| Non-contact Distance | 7.5mm |
| Sample Height | 0~150mm |
| Distance Adjustment Method | Manual adjustment(test height can be stored) |
| Measuring Mode | Sample mode/QC Mode/Continuous statistics mode |
| Locating Method | Camera Locating |
| Color Space | CIE LAB,XYZ,Yxy,LCh,CIE LUV,HunterLAB |
| Color Difference Formula | ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00,ΔE(Hunter) |
| Other Colorimetric Index | WI(ASTM E313，CIE/ISO,AATCC,Hunter)，YI(ASTM D1925，ASTM 313),TI(ASTM E313，CIE/ISO), |
| Metamerism Index MI, Staining Fastness, Color Fastness, Color Strength, Opacity | |
| Observer Angle | 2°/10° |
| Illuminant | D65,A,C,D50,D55,D75,F1,F2(CWF),F3,F4,F5,F6,F7(DLF),F8,F9,F10(TPL5),F11(TL84),F12(TL83/U30) |
| Displayed Data | Spectrogram/Values, Samples Chromaticity Values, Color Difference Values/Graph, Chromaticity Graph, Color Simulation, PASS/FAIL Result, Color Offset |
| Measuring Time | About 1.5s |
| Data Storage | Sample mode + QC mode: 30,000; Continuous statistics mode: 10,000 |
| Repeatability | Spectral reflectance: Standard deviation within 0.08% |
| Chromaticity value: Within ΔE*ab 0.05 (When a white calibration plate is measured 30 times at 5 second intervals after white calibration) | |
| Inter-instrument Error | Within ΔE*ab 0.25（Average for 12 BCRA Series II color tiles) |
| Measurement Mode | Single Measurement, Average Measurement(2 ~ 99 times) |
| Dimension | 330*250*370mm |
| Weight | About 10 kg |
| Power Supply | DC 24V, 3A Power Adapter |
| Illuminant Life Span | 5 years, more than 3 million times measurements |
| Display Screen | 7" TFT Capacitive Screen-touch Display |
| Data Port | USB/RS-232 |
| Language | Simplified Chinese,Traditional Chinese,English |
| Working Environment | Temperature: 0~40℃; Humidity: 0~85% (No Condensation); Altitude < 2000m |
| Storage Environment | Temperature: -20~50℃; Humidity: 0~85% (No Condensation) |
| Standard Accessory | Power Adapter, User Manual, USB cable, Standard Calibration Board, Black Calibration Cavity, |
| Notes | The specifications are subject to change without notice. |
Technical specifications
| Weight | 12 kg |
|---|---|
| Manufacturer | Kalstein |
